Hoonigan Garage: hp 1JZ Nissan SX

Turbocharged Toyota JZ engine swap, Ford gray paint and rebuilt BBS LM wheels are just a few of the things that make this S14 effin' amazing.

The Nissan SX (S14) is one of the most popular and affordable rear-wheel-drive sports cars of all-time. Because of this, it is also one of the most modified Japanese coupes in history and a car we've showcased hundreds of times across our channels. Who can forget Omar Cabrera's red RB-swapped and extreme stance car? Or Kyle Murphy's Laguna Seca Blue KA-turbocharged rendition? Perhaps April Taylor's haven for all things JDM? These are just a few recent examples of awesome s and we haven't even got to all the gems published in our magazine archives dating back to the '90s.

Today, we have another all-star to add to the books; a SX that was destined for endless thrashing in the "burnyard" but ended up being one of the sweetest S14 project cars within the last decade. Give a warm welcome to Vin Anatra of Hoonigan!

What's a crazy about Vinny's story is that I met him about 14 years ago when I just started as the Features Editor at eurotuner magazine. He was a VW owner and a "dubber", as was I, with my Silverstone Mk4 GTI. I can remember shooting his brother's Mk3 GTI for the magazine. Anyway, it's been several years since I've touched base with him so when his name popped up with this beautiful S14 build, let's just say I had an exciting "oh shit" moment, and was happy to reach out and connect with him again.

Before we jump into my interview with Vinny, there are some things I wanted to highlight about his and what makes it so special. Maybe his VW background is still lingering because the BBS LM wheels and Nardo gray-style paint (though it's actually a Ford color), screams Euro flavor. The paint, body work and execution are top notch, which isn't a common thing to find in an S-chassis these days, not to mention there's no riveted-on fenders, overly loud body kit or big wing (in fact there's no wing, which is cool). It's super clean (dare I say sophisticated) and under the hood there's also the punch to back it up (I'm guessing he wouldn't be working at Hoonigan if it didn't). A turbocharged Toyota 1JZ-GTE tuned to whp with rockstar components from Rywire, Garrett, Bisimoto and more. Vinny's S14 is quite honestly a fresh-to-death take on Nissan's plus-year-old S14, and it's our pleasure to tell you all his story today.

1-on-1 INTERVIEW WITH VIN ANATRA

How'd you get into cars, Vinny?

I have always been into cars. My pops was a muscle car dude so that's what I knew growing up. I got really deep into cars when I lacerated my spleen riding BMX and I couldn't ride for a year. The car that hooked me into driving fun imports was actually a super junky Honda CRX! At that time, the Honda scene in New York was brutal! You couldn't own a decent Honda without chaining it to the ground every time you walked away from it. However, VWs didn't seem to have that issue. My brother and a few friends had just got VWs and that became a super fun clique of dudes messing with Mk3s and Corrados.

I remember your Mk4 GTI! If I recall dumped on air-ride and BBS RS!

Haha! Funny you'd remember that! I spent a lot of time building "show cars", which I guess now would be considered stance cars and that process really took me down a fun road of getting engulfed in the world. Learning how to do everything on my own from body work and paint, engine and trans builds, and even pioneering the early days of air ride You know, back when the manifolds were made out of brass fittings from a plumbing supply house. Ha!

Eventually we all grow up!

Yes, I always loved fast cars and my time with super slammed cars ran dry after one too many oil pan slams in NYC. I made the move over to more function focused builds. Sold off my VW and got an STI.

Can you give us the lowdown of the project cars you've built?

Man, I have had a lot but these are the more notable ones:

    • VW Mk4 GTI. The car that started it all for me. Shaved bay, big turbo, custom interior, custom body work, wide-lipped BBS RS Full forum "fu*kboi".
    • Subaru STI. Rotated , full suspension, more of an autocross build.
    • Mitsubishi Evo. FP Black, cams, E85, full dickhead street machine with whp. I lived on Long Island at the time and there was nothing else to do besides highway races.
    • BMW E36 M3 in Dakar Yellow. It was my first track car. I bought it as an ex-stance car with a lot of goodies, sold off the parts and made it a stout track car turned canyon machine when I moved to California.
    • BMW E46 M3. The car that really got me into tracking, time attack and suspension tuning. It also introduced me to a lot of the friends I have in the scene.
    • Ford Raptor. Supercharged, long travel, etc.
    • The S At the time I had my E46 M3 which is built for grip, it ran s and made hp. I work at Hoonigan so I can't not have a car to rip burnouts and do all sorts of stupidity with. I wanted to build something that was just for fun and thrashing on, so what better than a SX?

What was your overall goal for the build?

The plan was to build a junky thrasher car, but one nice part lead to another and before I knew it, I was building a nice car. How does that always happen? I wanted something SIMPLE, something that was a no brainer to run and I didn't have to worry about, owning a BMW is too much of that as it is. The JZ engine is just that. Slap a turbo and some bits on it and rock out without worry. No, really, all I have done is frequent oil changes and this thing bangs limiter all day and eats it up. Toyota and Yamaha killed it on this engine. It's basically a YZ of car engines.

How long did the project take?

The build process took about a year working on it around a hectic work schedule, so it was a 'nights and weekends' project with me and my girl. I subbed out some fab work and Rywire did all of the engine and body harness.

What are your favorite parts about your build?

Definitely the entire engine and powertrain setup. The sound and power delivery of the JZ with the Garrett GTXR is amazing and so much fun. It puts a smile on my face every time! I love the exhaust note along with the noise of the compressor. Friends joke that it literally sounds like it's out of Fast & Furious.

Were there any major challenges?

Finding the time to work on it! It's a so it's pretty darn simple to build; however, Hoonigan was growing rapidly so work was slammed, despite looking like all we do is goof off all day!

Was it Hoonigan that brought you out to California or something else?

Yeah, a good buddy I made through the VW scene had introduced me to the [magazine] crew, which turned out to be Brian Scotto and later the Ken Block Racing team. One day I got a text from Scotto, "Yo, it's Scotto. Job opening at Hoonigan". I hated my current job in New York, so I packed all my crap into my E36 m3 and Jeep Wrangler and moved out 15 days later.

Sounds like it's worked out ever since! What's been your role there so far?

When I started at Hoonigan we were six people. With a rapidly growing company, I've done damn near everything under the roof. Currently I run the Business Development department handling all media partners and brand collaborations.

What are some of the accomplishments that you've achieved at Hoonigan?

Most of the time I feel like we are still a bunch of idiot kids trying to figure it out, but then I step back and look at all we've accomplished. The Hoonigan brand has grown tremendously over the last few years and it is all thanks to a super dedicated team driven by passion. I don't personally take credit for anything, but I'd like to think I've been an integral part of the growth and success of the brand.

Anything else to add on the Hoonigan front?

Our mission is to continue to show people that you can have fun with cars at any capacity. From low buck builds to multi-million dollar films, just go enjoy your car!

What's next for the S14 or perhaps a new project is around the corner?

I am a bit up in the air. The S14 is a great street machine and has been about as low maintenance as I could have ever imagined. I have considered turning it into a time attack car since it is very light at 2,lbs, makes good power and has all the datalogging capabilities with the AEM ECU. I have also considered selling it and building something else, maybe an F20C-powered BMW or an E36 time attack car. Part of me still wants that junky drift car, something to smash on and not have to worry about it, but maybe I'm not cut out for having a car that I can smash into a wall and leave it. Maybe I should just do that to more cars in the Hoonigan fleet Haha!

Download the high resolution image of Vinny's Super Street cover.

Tuning Menu
Car: Nissan SX (S14)
Owner:Vincent Anatra
Hometown:Queens, NY
Occupation:VP of Business Development at Hoonigan
Instagram:@vin_tra
Power:whp; lb-ft
Engine:1JZ-GTE VVTI liter inline-six engine swap; Garrett GTXR Gen II turbo with A/R V-band turbine housing; Plazmaman billet intake manifold, fuel rail, throttle body, Plazmaclamps; Future Fab V-band exhaust manifold; Chase Bays tucked radiator, brake booster delete, clutch slave; Deatschwerks 1,cc injectors; Radium Engineering fuel pressure regulator; Alariatech oil catch can; Thorn Industries coil pack
Drivetrain:OEM CD00A six-speed transmission; Collins adapter kit; Serielnine shifter; DriveshaftPro one-piece aluminum driveshaft; OS Giken Superlock way limited slip differential
Engine Management:AEM Infinity ECU; Rywire PDM and chassis harness; Bisimoto Flex Fuel tune
Footwork & Chassis:KW Clubsport two-way coilovers; ISR Performance suspension arm package; Team Hang Loose drop spindles
Brakes:OEM ZX Twin Turbo front and rear brake conversions; dual Z32 rear calipers
Wheels & Tires:18x" front, 18x" rear BBS LM wheels (reverse mounted); /40R18 front, /40R18 rear Falken RTk+ tires
Exterior:JDM front bumper; Origin Lab 55mm over-fenders; Seibon carbon hood, doors, panels and trunk; Ford Lead Foot Gray paint by Strassesport
Interior:Recaro Profi XL seats; Street Faction Engineering super low seat brackets; Chasing JS custom titanium panels; AEM CD-5 digital dash display; flocked dash; Renown steering wheel; NRG Innovations hub adapter
MotorTrend LogoTHE LATEST IN CAR NEWS

EMAIL NEWSLETTER SIGN-UP!

Share on FacebookShare on Twitter

Sours: https://www.motortrend.com/features/hoonigan-1jz-swapped-nissan-s14/
Hello everyone. Decided to make a thread highlighting the progression of my S-Chassis during my winter build.

Anyways, my name is Alex. I'm from St. Louis, Missouri. I'm a college student and focus my time and energy to work, bills, cars, and school work.

On to the car!

These are the previous outlines of the car before late last year.
Time to bring everyone up to speed.
Background info on the car:
1995 Nissan 240sx Base Model
Emerald Blue Paint
69F S14 SR20DET from a 1998 Nissan Silvia
Nismo Motor/Transmission Mounts
Mishimoto Radiator/Flex-a-Lite-Fans/Samco Hoses
Front Mount Intercooler/Sard BOV
Z32 MAF/Apex'i SAF-C Tuned by myself...
Greddy Profec B-Spec II Boost Controller set at 11lbs.
Exedy Stage 2 Clutch
Greddy 'Trust' 3" Downpipe

6-Point Roll Cage (1.75''x0.95 DOM Tubing) Nascar DoorBars
Recaro SPG Pole Position with Sparco 4-Point Harness
Powered by Max Coilovers
Q45 Brakes
Powered by Max Hydraulic Hand Brake
Tein Tension Rods/Tie Rods/Tower Brace
Tanabe Front Sway Bar, Whiteline Rear Sway Bar
Enkei RPF1 SBC paired with Muteki Purple Chrome lug nuts (17x9.5+18 & 17x10+18)
MB Battle Gunmetal (17x9.5+15)





This was my 2nd SR. I sought reliability after the 1st one blew up.

This winter, I decided to take on a project I've really been intrigued on doing for quite some time. Originally, I was going to pick up a MX83 Cressida and swap a 1JZ into there. However, I realized it would be much more neat in the S14.

Reasons for choosing this power plant?
- Forged Bottom End
- Inline 6
- R154
Browsing supraforums, I always get a kick out of the noobie threads titled: "How Much Boost is Safe" etc. etc. Everyone always responds, "whatever the fuck you want" xD. Lastly, I can keep the engine in relatively stock form and attain my power goals.


Tear Down Begins. October 2010.
Also, test fitting my new, err used Version Select Type II

SR is out.
I didn't care to document this too much. You all have seen a SR swap.

De-greased.

The New Engine/Transmission. Also, the adapted Engine Mounts and Transmission Crossmember. Courtesy of ZeroLift.

The following takes place from December 2010-January 2011:

Avid Solid Mounts

Sanding down the front Cam Covers.

Maintenance.

2JZ Water Pump Installed.

New Timing Belt
Front Crank Seal
Cam Seals

More cleaning.

HKS 264 Cams.

Looking much better.
Driftmotion Aluminum Pulley Kit installed as well.

Shot of the radiator.
Griffin 2 Core, 3" Thick.

Did a test fit.
Oil Pan and the Sway Bar contact. Looking into spacers or the Sikky front sway bar.

See what Salt does to the underchassis?
Old Subframe, damaged. Primary reason for replacement is due to the fact that a PO cut square holes for the front diff mounts to put a wrench on the top of the nuts.

Idiots.


Meters.
Apex'i EL II
- Boost, Water Temp, Oil Temp, Control Box


ACT Stage 4 Clutch, 3200 Pressure Plate.

60-1
.70 A/R
4" Inlet.
GT35 sizing.

Setrab Oil Cooler, Spal Fan.

2JZ AEM EMS
Dr. Tweak Jumper Harness
Apex'i Big Power Intercooler 24x9x4.75"

FUuuuuuuu.
Hours of the air hammer, and these damn collars are un-seized.

New subframe with PBM Risers installed.
Yes, I know I'm missing the driver side Traction Arm; was still snagging the seized bolt off the old subframe.

Intake off. Installing the wiring harness.


Shot of the exhaust manifold and external mounting.

Looks so bare.
Re-surfaced OEM Flywheel.
ARP Flywheel bolts installed.

Ready for the motor!

Fuel Rail and the 680 CC Injectors

Doing work!

Re-assembled.

Mated and ready for installation.

March 2011:


1JZ Ecu Plugs
Nissan f4 Connector

Ignitor mounted.
Fuel lines ran to the trunk.

Mounted to the driver side frame rail.


Shot of the SS Clutch lines and the new OEM Slave Cylinder

Lines mounted.
Rubberized undercoating on the underbody.

Wire-wheeling the trunk.

Big Bird thew up.

-6 Fittings!

Oil Return Assembled.
Aeromotive FPR Mounted!
Sours: https://zilvia.net/f/showthread.php?t=376821
  1. Altium designer 18
  2. Blue drinking glasses
  3. Profit taker warframe
  4. Washable pink paint

Hoonigan Garage: 550hp 1JZ Nissan 240SX

Turbocharged Toyota JZ engine swap, Ford gray paint and rebuilt BBS LM wheels are just a few of the things that make this S14 effin' amazing.

The Nissan 240SX (S14) is one of the most popular and affordable rear-wheel-drive sports cars of all-time. Because of this, it is also one of the most modified Japanese coupes in history and a car we've showcased hundreds of times across our channels. Who can forget Omar Cabrera's red RB-swapped and extreme stance car? Or Kyle Murphy's Laguna Seca Blue KA-turbocharged rendition? Perhaps April Taylor's haven for all things JDM? These are just a few recent examples of awesome 240s and we haven't even got to all the gems published in our magazine archives dating back to the '90s.

Today, we have another all-star to add to the books; a 1995 240SX that was destined for endless thrashing in the "burnyard" but ended up being one of the sweetest S14 project cars within the last decade. Give a warm welcome to Vin Anatra of Hoonigan!

What's a crazy about Vinny's story is that I met him about 14 years ago when I just started as the Features Editor at eurotuner magazine. He was a VW owner and a "dubber", as was I, with my Silverstone Mk4 GTI. I can remember shooting his brother's Mk3 GTI for the magazine. Anyway, it's been several years since I've touched base with him so when his name popped up with this beautiful S14 build, let's just say I had an exciting "oh shit" moment, and was happy to reach out and connect with him again.

Before we jump into my interview with Vinny, there are some things I wanted to highlight about his 240 and what makes it so special. Maybe his VW background is still lingering because the BBS LM wheels and Nardo gray-style paint (though it's actually a Ford color), screams Euro flavor. The paint, body work and execution are top notch, which isn't a common thing to find in an S-chassis these days, not to mention there's no riveted-on fenders, overly loud body kit or big wing (in fact there's no wing, which is cool). It's super clean (dare I say sophisticated) and under the hood there's also the punch to back it up (I'm guessing he wouldn't be working at Hoonigan if it didn't). A turbocharged Toyota 1JZ-GTE tuned to 515whp with rockstar components from Rywire, Garrett, Bisimoto and more. Vinny's S14 is quite honestly a fresh-to-death take on Nissan's 30-plus-year-old S14, and it's our pleasure to tell you all his story today.

1-on-1 INTERVIEW WITH VIN ANATRA

How'd you get into cars, Vinny?

I have always been into cars. My pops was a muscle car dude so that's what I knew growing up. I got really deep into cars when I lacerated my spleen riding BMX and I couldn't ride for a year. The car that hooked me into driving fun imports was actually a super junky Honda CRX! At that time, the Honda scene in New York was brutal! You couldn't own a decent Honda without chaining it to the ground every time you walked away from it. However, VWs didn't seem to have that issue. My brother and a few friends had just got VWs and that became a super fun clique of dudes messing with Mk3s and Corrados.

I remember your Mk4 GTI! If I recall... dumped on air-ride and BBS RS!

Haha! Funny you'd remember that! I spent a lot of time building "show cars", which I guess now would be considered stance cars and that process really took me down a fun road of getting engulfed in the world. Learning how to do everything on my own from body work and paint, engine and trans builds, and even pioneering the early days of air ride... You know, back when the manifolds were made out of brass fittings from a plumbing supply house. Ha!

Eventually we all grow up!

Yes, I always loved fast cars and my time with super slammed cars ran dry after one too many oil pan slams in NYC. I made the move over to more function focused builds. Sold off my VW and got an STI.

Can you give us the lowdown of the project cars you've built?

Man, I have had a lot but these are the more notable ones:

    • VW Mk4 GTI. The car that started it all for me. Shaved bay, big turbo, custom interior, custom body work, wide-lipped BBS RS... Full forum "fu*kboi".
    • 2005 Subaru STI. Rotated 3076, full suspension, more of an autocross build.
    • 2006 Mitsubishi Evo. FP Black, cams, E85, full dickhead street machine with 600whp. I lived on Long Island at the time and there was nothing else to do besides highway races.
    • BMW E36 M3 in Dakar Yellow. It was my first track car. I bought it as an ex-stance car with a lot of goodies, sold off the parts and made it a stout track car turned canyon machine when I moved to California.
    • BMW E46 M3. The car that really got me into tracking, time attack and suspension tuning. It also introduced me to a lot of the friends I have in the scene.
    • Ford Raptor. Supercharged, long travel, etc.
    • The S14. At the time I had my E46 M3 which is built for grip, it ran 275s and made 330hp. I work at Hoonigan so I can't not have a car to rip burnouts and do all sorts of stupidity with. I wanted to build something that was just for fun and thrashing on, so what better than a 240SX?

What was your overall goal for the 240 build?

The plan was to build a junky thrasher car, but one nice part lead to another and before I knew it, I was building a nice car. How does that always happen? I wanted something SIMPLE, something that was a no brainer to run and I didn't have to worry about, owning a BMW is too much of that as it is. The JZ engine is just that. Slap a turbo and some bits on it and rock out without worry. No, really, all I have done is frequent oil changes and this thing bangs limiter all day and eats it up. Toyota and Yamaha killed it on this engine. It's basically a YZ250 of car engines.

How long did the project take?

The build process took about a year working on it around a hectic work schedule, so it was a 'nights and weekends' project with me and my girl. I subbed out some fab work and Rywire did all of the engine and body harness.

What are your favorite parts about your build?

Definitely the entire engine and powertrain setup. The sound and power delivery of the JZ with the Garrett GTX3076R is amazing and so much fun. It puts a smile on my face every time! I love the exhaust note along with the noise of the compressor. Friends joke that it literally sounds like it's out of Fast & Furious.

Were there any major challenges?

Finding the time to work on it! It's a 240 so it's pretty darn simple to build; however, Hoonigan was growing rapidly so work was slammed, despite looking like all we do is goof off all day!

Was it Hoonigan that brought you out to California or something else?

Yeah, a good buddy I made through the VW scene had introduced me to the 0-60 [magazine] crew, which turned out to be Brian Scotto and later the Ken Block Racing team. One day I got a text from Scotto, "Yo, it's Scotto. Job opening at Hoonigan". I hated my current job in New York, so I packed all my crap into my E36 m3 and Jeep Wrangler and moved out 15 days later.

Sounds like it's worked out ever since! What's been your role there so far?

When I started at Hoonigan we were six people. With a rapidly growing company, I've done damn near everything under the roof. Currently I run the Business Development department handling all media partners and brand collaborations.

What are some of the accomplishments that you've achieved at Hoonigan?

Most of the time I feel like we are still a bunch of idiot kids trying to figure it out, but then I step back and look at all we've accomplished. The Hoonigan brand has grown tremendously over the last few years and it is all thanks to a super dedicated team driven by passion. I don't personally take credit for anything, but I'd like to think I've been an integral part of the growth and success of the brand.

Anything else to add on the Hoonigan front?

Our mission is to continue to show people that you can have fun with cars at any capacity. From low buck builds to multi-million dollar films, just go enjoy your car!

What's next for the S14 or perhaps a new project is around the corner?

I am a bit up in the air. The S14 is a great street machine and has been about as low maintenance as I could have ever imagined. I have considered turning it into a time attack car since it is very light at 2,600lbs, makes good power and has all the datalogging capabilities with the AEM ECU. I have also considered selling it and building something else, maybe an F20C-powered BMW 2002 or an E36 time attack car. Part of me still wants that junky drift car, something to smash on and not have to worry about it, but maybe I'm not cut out for having a car that I can smash into a wall and leave it. Maybe I should just do that to more cars in the Hoonigan fleet... Haha!

Download the high resolution image of Vinny's Super Street cover.

Tuning Menu
Car:1995 Nissan 240SX (S14)
Owner:Vincent Anatra
Hometown:Queens, NY
Occupation:VP of Business Development at Hoonigan
Instagram:@vin_tra
Power:515whp; 460 lb-ft
Engine:1JZ-GTE VVTI 2.5-liter inline-six engine swap; Garrett GTX3076R Gen II turbo with .81 A/R V-band turbine housing; Plazmaman billet intake manifold, fuel rail, throttle body, Plazmaclamps; Future Fab V-band exhaust manifold; Chase Bays tucked radiator, brake booster delete, clutch slave; Deatschwerks 1,200cc injectors; Radium Engineering fuel pressure regulator; Alariatech oil catch can; Thorn Industries coil pack
Drivetrain:OEM CD00A six-speed transmission; Collins adapter kit; Serielnine shifter; DriveshaftPro one-piece aluminum driveshaft; OS Giken Superlock 1.5-way limited slip differential
Engine Management:AEM Infinity ECU; Rywire PDM and chassis harness; Bisimoto Flex Fuel tune
Footwork & Chassis:KW Clubsport two-way coilovers; ISR Performance suspension arm package; Team Hang Loose drop spindles
Brakes:OEM 300ZX Twin Turbo front and rear brake conversions; dual Z32 rear calipers
Wheels & Tires:18x9.5" front, 18x10.5" rear BBS LM wheels (reverse mounted); 235/40R18 front, 245/40R18 rear Falken RT615k+ tires
Exterior:JDM front bumper; Origin Lab 55mm over-fenders; Seibon carbon hood, doors, panels and trunk; Ford Lead Foot Gray paint by Strassesport
Interior:Recaro Profi XL seats; Street Faction Engineering super low seat brackets; Chasing JS custom titanium panels; AEM CD-5 digital dash display; flocked dash; Renown steering wheel; NRG Innovations hub adapter
MotorTrend LogoTHE LATEST IN CAR NEWS

EMAIL NEWSLETTER SIGN-UP!

Share on FacebookShare on Twitter

Sours: https://www.motortrend.com/features/hoonigan-1jz-swapped-nissan-s14/
1JZ vs LS - What's the Better Engine Swap? (In Depth Comparison)
Hello everyone. Decided to make a thread highlighting the progression of my S-Chassis during my winter build.

Anyways, my name is Alex. I'm from St. Louis, Missouri. I'm a college student and focus my time and energy to work, bills, cars, and school work.

On to the car!

These are the previous outlines of the car before late last year.
Time to bring everyone up to speed.
Background info on the car:
Nissan sx Base Model
Emerald Blue Paint
69F S14 SR20DET from a Nissan Silvia
Nismo Motor/Transmission Mounts
Mishimoto Radiator/Flex-a-Lite-Fans/Samco Hoses
Front Mount Intercooler/Sard BOV
Z32 MAF/Apex'i SAF-C Tuned by myself
Greddy Profec B-Spec II Boost Controller set at 11lbs.
Exedy Stage 2 Clutch
Greddy 'Trust' 3" Downpipe

6-Point Roll Cage (''x DOM Tubing) Nascar DoorBars
Recaro SPG Pole Position with Sparco 4-Point Harness
Powered by Max Coilovers
Q45 Brakes
Powered by Max Hydraulic Hand Brake
Tein Tension Rods/Tie Rods/Tower Brace
Tanabe Front Sway Bar, Whiteline Rear Sway Bar
Enkei RPF1 SBC paired with Muteki Purple Chrome lug nuts (17x+18 & 17x10+18)
MB Battle Gunmetal (17x+15)





This was my 2nd SR. I sought reliability after the 1st one blew up.

This winter, I decided to take on a project I've really been intrigued on doing for quite some time. Originally, I was going to pick up a MX83 Cressida and swap a 1JZ into there. However, I realized it would be much more neat in the S

Reasons for choosing this power plant?
- Forged Bottom End
- Inline 6
- R
Browsing supraforums, I always get a kick out of the noobie threads titled: "How Much Boost is Safe" etc. etc. Everyone always responds, "whatever the fuck you want" xD. Lastly, I can keep the engine in relatively stock form and attain my power goals.


Tear Down Begins. October
Also, test fitting my new, err used Version Select Type II

SR is out.
I didn't care to document this too much. You all have seen a SR swap.

De-greased.

The New Engine/Transmission. Also, the adapted Engine Mounts and Transmission Crossmember. Courtesy of ZeroLift.

The following takes place from December January

Avid Solid Mounts

Sanding down the front Cam Covers.

Maintenance.

2JZ Water Pump Installed.

New Timing Belt
Front Crank Seal
Cam Seals

More cleaning.

HKS Cams.

Looking much better.
Driftmotion Aluminum Pulley Kit installed as well.

Shot of the radiator.
Griffin 2 Core, 3" Thick.

Did a test fit.
Oil Pan and the Sway Bar contact. Looking into spacers or the Sikky front sway bar.

See what Salt does to the underchassis?
Old Subframe, damaged. Primary reason for replacement is due to the fact that a PO cut square holes for the front diff mounts to put a wrench on the top of the nuts.

Idiots.


Meters.
Apex'i EL II
- Boost, Water Temp, Oil Temp, Control Box


ACT Stage 4 Clutch, Pressure Plate.


A/R
4" Inlet.
GT35 sizing.

Setrab Oil Cooler, Spal Fan.

2JZ AEM EMS
Dr. Tweak Jumper Harness
Apex'i Big Power Intercooler 24x9x"

FUuuuuuuu.
Hours of the air hammer, and these damn collars are un-seized.

New subframe with PBM Risers installed.
Yes, I know I'm missing the driver side Traction Arm; was still snagging the seized bolt off the old subframe.

Intake off. Installing the wiring harness.


Shot of the exhaust manifold and external mounting.

Looks so bare.
Re-surfaced OEM Flywheel.
ARP Flywheel bolts installed.

Ready for the motor!

Fuel Rail and the CC Injectors

Doing work!

Re-assembled.

Mated and ready for installation.

March


1JZ Ecu Plugs
Nissan f4 Connector

Ignitor mounted.
Fuel lines ran to the trunk.

Mounted to the driver side frame rail.


Shot of the SS Clutch lines and the new OEM Slave Cylinder

Lines mounted.
Rubberized undercoating on the underbody.

Wire-wheeling the trunk.

Big Bird thew up.

-6 Fittings!

Oil Return Assembled.
Aeromotive FPR Mounted!
Sours: https://zilvia.net/f/showthread.php?t=

Swap 1jz s14

1JZGTE VVTI Engine R Transmission Swap Kit for SX S13 S14 1JZ 1JZ-GTE

CXRacing Engine + Transmission Mounts Swap Kit For Nissan SX S13 S14 S15 with Toyota 1JZ-GTE VVTI and R Transmission Swap

*One or More Part(s) Has Registered Patent(s)*

Application:
-Chassis: Nissan SX S13 S14 S15
(Parts are Developed on from US Model Left Hand Drive Chassis, But Fits Both LHD and RHD)
-Motor: Toyota 1JZ-GTE VVTI
-Transmission: R

Product Being Sold:
-Engine + Transmission Mounts
-This is CXRacing's Newest Products for the Application Stated Above. All Parts Are Developed from Ground Up in Our R&D Center in USA, Designed and Built for Improved Performance Gains, with Excellent Fitment and Easy Installation.

Product Info and Spec:
Motor / Transmission Mounts:
-Heavy Duty 7 Gauge (") Thick Stainless Steel Panel, with Brace Offers Strong Support
-Adjustable Slotted Bolt Holes
-Polyurethane Bushing Mounts
-Patent Pending Design of Motor Mount is Billet Stainless Steel, Excellent Strength

Notes:
-Off Road or Track Use ONLY, NOT for Street Use
-Due to the Complexity of Swapping a Motor to Different Chassis, Please Make Sure that You Understand the Application Stated Here are the Right Parts for Your Project
-Parts Being Sold are the Kit Being Advertised ONLY. Other Parts Shown on Pictures are for Demo Only (of Our Complete Swap Kit). Check Our Other Website Items.

Below Are Installation Pictures:

Click Below Picture to Watch Installation Video of 2JZ-GTE Parts









Click Below Picture to See Youtube Video of Related Product


Highlights:
-Especially Designed, Made for the Application Stated
-Fully Tested, Simple Easy Installation
-Offers Excellent Performance Gains
-One of the Best Kits on the Market, with High Quality Products and Affordable Pricing

Items_Included:
-Engine + Transmission Mounts

Below Are Installation Pictures:











Sours: https://www.cx-garage.com/
NEW Build! - We Swap a 1jz Into Vin's Nissan s14 Drift Project

.

You will also like:

.



1 2 3
